UL94 Horizontal And Vertical Flammability Testing Machine SL-FL18

Product introduction:
Horizontal and Vertical Flammability Testing Machine UL 94 flame chamber. Horizontal flame chamber, vertical flame chamber For the flammability testing of plastic materials used in consumer electric devices and appliances. Stainless steel construction with black interior and large sliding window for easy viewing. Includes a fully adjustable specimen support and precision gas flow controls.

Product parameters:

Timer	0-999.9s+/-0.1s (adjustable)
Flame Height	20mm+/-2mm to 180mm+/-10mm(adjustable)
Gas	98% methane
Temperature testing range	0-1000degree
Dimensions(L*W*H)	1100 x 700 x 1300mm
Weight	128kg
Standards	UL 94-2006 IEC 60695-11-3 IEC 60695-11-4

Product Feature and Application Testing Standards:
UL 94-2006 IEC 60695-11-3 IEC 60695-11-4
UL94:Tests for Flammability of Plastic Materials for Parts in Devices and Appliances
UL94HB: Horizontal Burning Test
V-0,1,2: 20mm Vertical Burning Test
94-5VA,B: 500W(125mm) Vertical Burning Test
94VTM-0,1,2: Thin Material Vertical Burning Test
94HBF,94HF-1,2 : Horizontal Burning Foamed Material Test
IEC 60695-11-10:Fire hazard testing - Part 11-10: Test flames - 50 W horizontal and vertical flame test methods
IEC 60695-11-20: Fire hazard testing - Part 11-20: Test flames - 500 W flame test methods
IEC 60695-11-4:Fire hazard testing - Part 11-4: Test flames - 50 W flames-Apparatus and conformational test method
IEC 60695-11-3:Fire hazard testing - Part 11-3: Test flames - 500 W flames-Apparatus and conformational test method

Product Details:

Kinds	500W(5V class ) / 50W(HB/Vclass)
Test Flame	500W(burning test for V-0,V-1,V-2 classification)   /50W(burning test for V-0,V-1,V-2 classification)
Burner Tube	Internal diameter
Φ 9.5mm±0.3mm  Internal diameter	Φ 9.5mm±0.3mm,
Burning Angle	0°,20°,45° /0°,20°,45°
Thermocouple	Type K (Ni/Cr - Ni/Al) / Type K (Ni/Cr - Ni/Al)
Thermocouple Size	0.5 mm X 0.5 mm
Standard Copper Block	9mm±0.01mm/5.5mm±0.01mm,
Weight	10g±005g before drilling. 76g±0.01g before drilling.
Time for Temperature to Increase	From 100°C±5°C to 700°C±3°C; 54s±2s (preset); /From 100°C±5°C to 700°C±3°C; 44s±2s (preset)
Gas Flow	965±32ml/min/105±10ml/min
Gas Supply	methane,min.98% purity /methane,min.98% purity
Water-column	125m±5mm ‹10mm
Test Time	54±2s/44±2s
Flame Height Indicator	40±1mm/ 20±1mm
Volume Of Chamber	>0.5m³, black interior />0.5m³, black interior
